A-A-58041
15 MARCH 95
COMMERCIAL ITEM DESCRIPTION
TRAILER, LD-3 CONTAINER, SIDE TRANSFER, TURNTABLE
The General Services Administration has authorized the use of this commercial item description.
.
1. SCOPE:
This Commercial Item Description (CID) describes a commercial LD-3 container trailer having single
container capability. This trailer shall have side transfer capability, a fully rotatable deck, four-wheel
coordinated steering, and a capacity of 3500 pounds.
2. SALIENT CHARACTERISTICS : Failure of the trailer to meet the following salient characteristics
will require rejection of the offer.
2.1 The trailer shall be free from faulty construction or any defect which affects appearance,
serviceability, or durability. All components and accessories shall be represented in the manufacturer's
sale data as standard or optional. The trailer shall be representative of the quality and workmanship
found in trailer offered for new commercial sale.
2.2 The following is the purchaser provided data:
2.2.1 The deck shall handle one fully loaded LD-3 cargo container (gross weight 3500 pounds).
2.2.2 The deck shall be of the side loading type, accepting containers from either side, with sufficient
width to accommodate container misalignment.
2.2.3 The deck shall be furnished with suitable stops, guides, and vertical restraints. The container stops
and vertical restraints shall be designed to retract into the deck and then automatically return to position
once the container is positioned onto the roller deck.
2.2.4 A walkway with a nonskid surface shall be provided across the deck to allow personnel a tread
surface when pushing a container off the deck.
2.2.5 The height to the top of the deck rollers, as measured from the ground shall be 20 inches, plus or
minus 0.25 inch.
Beneficial comments, recommendations, additions, deletions,
clarifications, etc, and any data which may improve this document
should be sent to: WR-ALC/TILC Robins AFB, GA 31098-1647
.
AMSC N/A
FSC 3920
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited
